Description
General
- Frequency Range: 446.00625 – 446.09375MHz (HX446E)
- Channels: 16 Channels
- Channel Spacing: 12.5 kHz ⁄ 25 kHz
- Communication Method: Simplex ⁄ semi duplex
- Antenna Impedance: 50 ohm
- Antenna: Whip / stubby
- Battery Type: 1800 mAh Li–Ion battery pack
- Power Supply Voltage: 7.4V DC
- Current Drain (nominal): TBA
- Duty Cycle (5/5/90): TBA
- Microphone: Internal condenser microphone
- Operating Temperature: –20° to +55°
- Size (mm): 61(W) x 100(H) x 31(D)
- Weight: 274g with battery and aerial
Transmitter
- Power Output: 0.5W
- Modulation: 8K0F3E⁄16K0F3E
- Oscillator Method: PLL
- Frequency Stability: < ±0.00025% (±2PPM)
- Maximum Deviation: ±2.5 kHz(Narrow)⁄ ±5 kHz(Wide)
- Audio Distortion: < 5% (1 kHz 60%)
- Spurious Emission: –68 [dBc]
- Hum & Noise: –40 [dB]
Receiver
- Receiver Type: Double Super Heterodyne type
- Sensitivity: –0.25uV (12dB SINAD)
- Frequency Stability: ±0.00025%(±2PPM)
- Spurious Rejection: –60 dB
- Adjacent Channel Selectivity: –60 dB (Narrow) , –70 dB (Wide)
- Distortion: < 3% Typical
- Hum & Noise: –40 dB
- Audio Output: 1W
- Speaker Size: 38 mm
SKU: HX446E
